Rhombus

Rhombus R230

Rhombus R230

Regular price $0.00
Regular price Sale price $0.00
Sale Sold out
Quantity
View full details

Specification

 WiFi 802.11ac, 802.11/g/n, 2.4Ghz and 5Ghz
Onboard Storage Included
  • 128GB or 20 days
  • 256GB or 40 days
  • 512GB or 90 days
  • 1TB or 180 days
Resolution 5MP sensor, 2592 x 1944 resolution
Ethernet 10 / 100Mbps, MDI / MDI-X Auto Sensing
Pan / Tilt / Zoom 2.8x Optical Zoom
Power-Over-Ethernet Standard 802.3af for one-cable installation
Field of View
  • 84˚-122.2˚ Diagonal FoV
  • 53.1˚-110.1˚ Horizontal FoV
  • 38.6˚-53.1˚ Vertical FoV
Power Consumption Max 9.4 watts
Focal Length 2.8mm
Operating Temperature
  • -55 ̊ to 55 ̊C
  • -67 ̊ to 131 ̊F
Dimensions 117mm (4.61in) x 83.5mm (3.29in)
Operating Humidity 10-90%, no condensation
Weight 0.42kg (0.91lbs)
In the Box Mounting screws and anchors, RJ45 waterproofing grommet
Weather Resistance IP66
Baseline Steady State 10 - 30 Kbps per camera
Impact Resistance IK10
HD WAN Live Streaming 530 - 720 Kbps per camera
Night Vision Infrared illuminators (100ft in low light)
Rhombus Sensor Network Compatible FCC, CE, IC, RCM, UKCA, TAA Compliant
10-Year Warranty Included
