| Resolution
|
Four 5MP sensor, 2592 x 1944 resolution |
| Aperture |
F/1.85 |
| Pan / Tilt / Zoom |
Up to 2X digital PTZ and up to 2x optical zoom |
| Field of View |
- 129 - 55° Diagonal FoV
- 94 - 43° Horizontal FoV
- 67 - 33° Vertical FoV
|
| Focal Length |
3.42mm - 6.85mm |
| Dimensions |
275mm (10.8 in) x 118 mm (4.6 in) |
| Weight |
3.63kg (8.00lbs) |
| Weather Resistance |
IP66 |
| Impact Resistance |
IK10 |
| Night Vision |
Infrared illuminators (100 ft with full FoV coverage) |
| Onboard Storage |
- 1TB or 40 days
- 2TB or 90 days
|
| Ethernet |
10 / 100Mbps, MDI / MDI-X Auto Sensing |
| Power-Over-Ethernet |
Single POE++ (802.3 bt) cable for simplified installation |
| Power Consumption |
Max 51 watts |
| Operating Temperature |
- -30˚ to 55˚ C
- -22˚ to 131˚ F
|
| Operating Humidity |
90% RH |
| In the Box |
Torx key, mounting screws, anchors, waterproofing kit |
| Baseline Steady State |
10 - 30 Kbps per camera |
| HD WAN Live Streaming |
530 - 720 Kbps per camera |
| Compliance |
CE/LVD Compliant, FCC, IC, UK, UL 62368-1, AUS, NZ, NDAA Compliant, TAA Compliant |
| Rhombus Sensor Network Compatible |
|
| 10-Year Warranty Included |
|
